LED Indicator Train Station Turnstile Security Wing Gates 600mm Channel Width

Place of Origin Shenzhen,China
Brand Name Hongchuangwei
Certification CE
Model Number CW507
Minimum Order Quantity 2
Price USD700-1300 per piece
Packaging Details wood cases
Delivery Time 5-8 working days
Payment Terms T/T
Supply Ability 100 pieces per day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
High Light

LED Train Station Turnstile


600mm Channel Train Station Turnstile


600mm Channel security speed gates

Leave a Message
Product Description

Hot Sale Indicator Wing Flap Turnstile Entrance System Gate


CW507 luxury wing gate channel, using STC CPU chip,DC brush motor,4 pairs of infrared detection sensors,long life and high stability,high efficiency and anti-tailing,support various IC/ID card readers,barcode readers,ID card reading,etc.It is easy to connect with the access control system.It is widely used in the entrance and exit control of CBD business centers, government and enterprise office buildings,high-end residential areas,kindergartens, etc.


  • Only authorized personnel can pass, and an audible and visual alarm will be issued when unauthorized personnel break in
  • Flexible selection of normally open and normally closed modes,two-way passing can also be set according to the flow of people,the opening and closing speed of the door wing can be set to improve the efficiency of the equipment
  • Anti-following tracking control technology, strictly preventing unauthorized personnel from passing through
  • Anti-pinch function, when the door wing is blocked during the reset process, it will automatically rebound or the motor will automatically stop working within the specified time, and the sound and light alarm will be issued at the same time
  • Anti-shock function, when the door opening signal is not received, the door wing is automatically locked, and the maximum impact force is 120Nm
  • With self-detection, self-diagnosis, and automatic alarm functions; sound and light alarm functions, including illegal intrusion alarm, anti-pinch alarm, and anti-tailing alarm
  • Remote control management function
  • LED passing direction indication, showing passing status
  • When the power is off, the door wings automatically retract into the chassis, the passage is in a clear state, and personnel can pass freely to prevent panic
  • With automatic reset function, after opening the door, the system will automatically cancel the user's permission for this pass if the user does not pass within the specified time,and you can set the pass time



Technical parameter
Product number CW507
Voltage AC220V±10%, 50HZ±10% HZ
Working temperature -25℃~70℃
Relative humidity 5%--80%
IP protection level 42
Rated power 20W
Input control signal Switch value (standard configuration does not include RS232, RS485)
Running speed 40 people/minute
Infrared beam 4 pairs
Number of trouble-free runs 2 million times
Average life span 3 million times
Channel width 600mm
Door wing material 15mm plexiglass, 35mm sponge body with soft wings
Product Size L 1400mm x W 300mm x H 990 mm
Channel frame National standard 1.2mm~1.5mm thick + 304 stainless steel
Package weight About 55 KG (single side road)
