AC110V Input Wing Gate Turnstile Card Reader Electronic Turnstile Gates

Place of Origin Shenzhen,China
Brand Name Hongchuangwei
Certification CE
Model Number CW515
Minimum Order Quantity 2
Price USD300~500 per piece
Packaging Details wood cases
Delivery Time 5-8 work days
Payment Terms T/T
Supply Ability 100 pieces per day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571


If you have any concern, we provide 24-hour online help.

Product Details
Product Model CW515 Power Supply Voltage AC110V
Working Environment Temperature -22℃~78℃ Relative Humidity 90%
IP Protection Level 57 Rated Power 25W
Input Control Signal Switch Quantity Standard Configuration Does Not Include RS232, 485 Running Speed (XX People/minute) 36 People/minute
High Light

AC110V speed gate turnstile


Card Reader speed gate turnstile


AC110V electronic turnstile gates

Leave a Message
Product Description

AC110V input wing gate turnstile flap barrier


Security flap turnstiles are highly configurable both in material and in features. This saves your budget and provides exactly the security solution you want.
Elegant and discreet security from our most compact, economic, and popular model.
Designed for high-traffic lobbies; exceeds safety and security requirements for a compact unit.
Fast-acting “angel wing” glass barriers retract fully into the pedestals upon authorization.


Movement performance
Door body: plexiglass plate, etc.
Drive mode: brush positioning driver
Safety touch: automatic opening after power failure
Power driven: brush motor
Door opening mode: split split
Opening and closing speed: 0.2 ~ 0.6s (user can set)
Channel width: 550mm;
Equipment noise: door opening and closing ≤ 30dB
Traffic speed: 35 persons / min in normally closed mode; 60 persons / min in normally open mode
Core life: 5 million times



Infrared radio 5 pairs
trouble-free operation 2 million times
average life span 3 million times
Channel width 850mm
Door wing material Plexiglass
Product size length 1200mm x width 300mm x height 990 mm
Channel frame 304 stainless steel
Packing weight bout 65 KG (single side lane)
