Access Control Supermarket Swing Gate IP54 130W High Speed Gate

  • Access Control Supermarket Swing Gate IP54 130W High Speed Gate
  • Access Control Supermarket Swing Gate IP54 130W High Speed Gate
  • Access Control Supermarket Swing Gate IP54 130W High Speed Gate
  • Access Control Supermarket Swing Gate IP54 130W High Speed Gate
  • Access Control Supermarket Swing Gate IP54 130W High Speed Gate
Place of Origin Shenzhen,China
Brand Name Hongchuangwei
Certification CE
Model Number CW406
Minimum Order Quantity 1 piece
Price Negotiable
Packaging Details wood cases
Delivery Time 7-15 working days
Payment Terms T/T
Supply Ability 100 pieces per day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Item Type Fast Speed Gate Dimension 1540mm (L) * 200mm (W) * 990(H) Mm
Passage Width ≤600 Mm IP Protection IP54
Rated Power 100W Input Control Signal Switch Value RS232, 485
Opening Speed 0.3~0.8 Seconds
Highlight

IP54 Supermarket Swing Gate

,

130W Supermarket Swing Gate

,

IP54 High Speed Gate
Leave a Message
Product Description

High Quality Access Control Compatible Fast Speed Gate Speed Turnstile Gate


CW406 high-end speed pass anti-collision swing gate, equipped with a brushless DC motor, 8 pairs of infrared detection sensors, long life and high stability,high efficiency and anti-tailing,supports various IC/ID card readers,barcode readers,and identity Card reader, etc.,easy to hook up with the access control system.Widely used in the entrance and exit control of CBD business centers,government and enterprise office buildings,high-end residential areas,kindergartens, etc.


Precise and Efficient, Unimpeded Passage
Adopting high-precision sensors and intelligent control algorithms, it features a fast response time of 0.3 seconds, supports bidirectional free passage, and has a maximum hourly throughput of 800 people. It meets the needs of high-traffic scenarios such as subways, venues, and office buildings, eliminating congestion and delivering a smooth passage experience.



Multiple Protections, Safe and Reliable



Anti-pinch and Anti-collision Design: Dual protection of infrared induction and mechanical buffering, which automatically rebounds when encountering obstacles, safely protecting the elderly, children, and those carrying luggage.



Abnormal Alarm System: Real-time monitoring of illegal intrusion and tailgating, combined with sound and light alarms, to ensure the safety of the premises.



Impact-resistant Structure: 304 stainless steel body with IP54 protection rating, resistant to wind, rain, and violent impacts, ensuring long-term stable operation.



Intelligent Interconnection, Worry-free Management



Multi-mode Control: Supports multi-dimensional verification such as card swiping, face recognition, QR code, and NFC, seamlessly connecting to access control systems and ticketing platforms.



Cloud Management: Remotely monitor device status, generate passenger flow reports, and adjust passage modes with one click, facilitating the digital upgrading of smart parks.



Low Power Consumption and Quiet Operation: Driven by a brushless DC motor, energy consumption is reduced by 40%, and the noise during 24-hour continuous operation is ≤45dB, making it environmentally friendly and more worry-free.



Customized Services, Fully Adaptable
A variety of chassis materials (stainless steel/tempered glass/acrylic), wing arm lengths, and opening angles are available, and personalized LOGO customization is supported, perfectly integrating into the aesthetic needs of commercial, transportation, campus and other scenarios.



 Product name CW406
Power Supply Voltage AC220V±10%,50/60HZ
Motor 60W brushless DC
Rated power 100W
 Material 304 stainless steel
Infrared 8 pairs
 Surface treatment Brushed finish
 Thickness  1.2mm
 Size 1540*200*990mm(Chassis)
Opening speed 0.5~1s
Passage Width 550-1190mm
Service Life 5 million cycles
Relative humidity ≤90%, no condensation
Gate opening signal relay
Drive current >10mA
 Working environment  -25℃~+70℃
Access Control Methods  Facial Recognition,Card Swiping,QR Code...
Applicable Locations Office buildings, scenic spots, apartments, schools, and more


Access Control Supermarket Swing Gate IP54 130W High Speed Gate 0

Access Control Supermarket Swing Gate IP54 130W High Speed Gate 1

Access Control Supermarket Swing Gate IP54 130W High Speed Gate 2

Access Control Supermarket Swing Gate IP54 130W High Speed Gate 3
