Entrance / Exit Swing Turnstile Gate Fully Automatic Bridge Type Two Way

Place of Origin China
Brand Name Hongchuangwei
Certification CE UL
Model Number CW401
Minimum Order Quantity 2
Price USD330 per piece
Packaging Details wood cases
Delivery Time 4-7 working days
Payment Terms T/T
Supply Ability 1000 pieces weekly

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Passing Speed 30-40person/min Power Supply AC220V±10%,50±10Hz
Weight 20KG Working Environment -25℃ To 70℃
Dimension 168 * 600 * 1050mm Open/ Close Time 2S
Relative Humidity ≤90% No Condensation Normal Service Life 4 Million Times
High Light

Entrance Exit swing turnstile gate


40 person/min swing turnstile gate


Pedestrian Access Control Swing Barrier Turnstile

Leave a Message
Product Description

Fully automatic bridge type two-way swing turnstile gate at entrance and exit



Thickened steel, support customization, quality assurance, durable, waterproof and rustproof
Support face recognition, fingerprint recognition, scan code recognition, document recognition
Anti-collision function, when there is no signal to open the brake, the swing arm is automatically locked
Fault prompt, fault self-check is convenient for users to use and maintain
Brushless motor for longer life
One-way two-way traffic can be set according to the use site
Can be used for smart community system solutions
Option 1: Face recognition, improve security and prevent identity impersonation
Face collection, face detection, feature extraction, and feature comparison


1. It has the functions of fault self-checking and alarm prompting, which is convenient for users to maintain and use;
2. It has automatic opening after power failure, self-checking when incoming calls and automatic recovery in locked state
3. There are a variety of working modes to choose from, you can read the card in two directions, or you can read the card while the other direction is prohibited, while reading the card and pass freely in the other direction, or one-way or two-way infrared induction, pedestrians can pass. After passing through, the infrared sensor closes the gate, and the working mode of the gate can be set through the main board menu.
4. After the pedestrian reads the valid card, the infrared detection will automatically close the gate or delay the gate after the pedestrian passes. The delay of 1-60 seconds can be set by the main board menu.
5. With automatic reset function. After the valid card is read, if the passer does not pass within the specified time, the system will automatically cancel the passer's current pass authority, and the limited pass time can be set by the administrator.
6. If a pedestrian forgets to read the card or reads an invalid card and enters the passage, the system will prohibit the pedestrian from passing and will issue an alarm, and the alarm will not be released until the pedestrian exits the passage; the valid card will be re-read to allow passage;
7. It has 485 remote control opening and closing functions to meet the special needs of users and fire safety requirements.
8. Anti-shock function, the telescopic arm automatically locks when no signal to open the gate is received;
9. Infrared/mechanical dual anti-pinch function, when pedestrians pass, infrared detection of pedestrians in the middle, the telescopic arm will not close the gate, the telescopic arm will automatically close after the pedestrian walks away, when the telescopic arm is blocked in the process of resetting, Automatic rebound or the motor automatically stops working within a specified time, and the force is very small, and an audible and visual alarm signal is issued at the same time;
10. It has a unified and standard external electrical interface, which can be connected with various reading and writing devices, which is convenient for system integration, and can realize remote control and management through the management computer.
11. It can automatically count the number of people passing in the direction of travel, and present it to the manager in an intuitive LED (optional) way, so that the manager can know the number of people passing in a certain direction.
12. It has a clear function of indicating the direction of passage, with intuitive LED passersby indicating whether it is possible to pass or not to pass.
13. It has the function of reading card with memory and without memory, and users can set it through the motherboard keyboard according to their own needs.
14. Through software settings, the total number of personnel in the venue can be limited to meet the special needs of some special occasions.
15. The whole system runs smoothly and has low noise;


Technical parameter
Product Model CW401
Voltage AC220V±10%,50HZ±10% HZ
Working temperature -25℃-70℃
Relative humidity ≤90% No condensation
Motor Brushless Motor
Rated power 40W
Input control signal Switch value (standard configuration does not include RS232, RS485)
Running speed 30~40 Person/minute
Infrared beam 1 Pair
Number of trouble-free runs 2 million times
Average life span 3 million times
Channel width 600mm~1600mm
Door wing material ¢25mm Stainless steel
Product Size ¢168mm x 600height 1050 mm
Channel frame National standard 1.5mm 304 stainless steel
Package weight About 25 KG (single side road)
