Pedestrian 0.5 Seconds Swing Barrier Turnstile SS304 With Face Recognition

Place of Origin Shenzhen,China
Brand Name Hongchuangwei
Certification CE
Model Number CW426
Minimum Order Quantity 10
Price USD300-500 per piece
Packaging Details wood cases
Delivery Time 5-8 working days
Payment Terms T/T
Supply Ability 100 pieces per day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571


If you have any concern, we provide 24-hour online help.

Product Details
Cabinet Material SS304 Arm Length 530 To 730mm
Direction Single Or Bi-direction (can Be Set) Package Carton Or Wooden Box
Certificates CE Power Supply AC100-240V
Passing Direction Single Directional / Bi-directional
High Light

Pedestrian Swing Barrier Turnstile


0.5 seconds Swing Barrier Turnstile


SS304 pedestrian security turnstiles

Leave a Message
Product Description

Swing turnstile Pedestrian passage gate scan face recognition all-in-one machine


Swing tursntile is an intelligent channel management equipment developed and produced by our company for many years. The equipment organically integrates mechanical, electronic, microprocessor control and various reading and writing technologies. By configuring a variety of different reading and writing equipment, adopting reliable safety protection devices, real-time alarm system and direction indicating interface, the intelligent control and management of the channel can be realized together in coordination.


The fuselage is made of stainless steel, which is solid and stable. There is an indicator reading and writing device on the chassis.
Powerful and intelligent mainboard, which can read the card in both directions, or read the card while the other direction is prohibited, or read the card while reading the card and pass freely in the other direction, and the working mode of the gate can be set through the mainboard menu
The gate movement, after the gate is released from the control, the gate needs to be manually pushed and released
Card-reading with memory improves efficiency, with card-reading memory and without memory function, the user needs to set the card after swiping N times, pass through N people continuously, and then close the door, suitable for places with high traffic
When there is illegal intrusion, the infrared detector will detect it and automatically turn on the alarm


Channel width 600mm-1100mm
Swing arm length outside the chassis ≤51cm
Opening speed 0.5 seconds
Number of people passing 40 people/minute
Working environment -40°C~80°C
Relative humidity ≤90%, no condensation
Gate opening signal relay
Cabinet material 304 stainless steel
Box thickness 1.5mm
Drive current >10mA
