Smart Barrier Turnstile Gate High Speed 0.5s Turnstile Entrance Gates For School

Place of Origin Guangdong,China
Brand Name Hongchuangwei
Certification CE UL
Model Number CW602
Minimum Order Quantity 2
Price USD579-1049 per piece
Packaging Details wood packing
Delivery Time 7-10 working days
Payment Terms T/T
Supply Ability 1000 pieces weekly

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571


If you have any concern, we provide 24-hour online help.

Product Details
Power Supply AC220V±10%, Input Interface 12v Level Signal Or Pulse Widt
Relative Humidity ≤90% No Condensation Lane Width 550mm
Number Of Passers 40 Persons/minute IP Protection Level 54
Drive Current >10mA Material Stainless Steel
High Light

Smart Barrier Turnstile Gate


school Barrier Turnstile Gate


0.5s turnstile entrance gates

Leave a Message
Product Description

Smart Entrance Security High-Speed Automatic Fast Speed Gate Swing Barrier Turnstile Gates With Access Control


High speed Turnstile Description:


1.The electric control adopts DC motor to drive stable and reliable, and has low failure rate. Ultra high light traffic indicator function: directional instructions are designed with ultra bright LED lights, indicating more prominently;

2.In the case of the person who has not swiped the card into the passageway, the equipment alarm will prompt the traveler to swipe the card.

3.The function of the reverse alarm system: when a pedestrian swipes the card, the device alarms the alarm.

4.Check the following function: when the first person swipes the card, the second person doesn't swipe the card and the device will alarm.

5.The bicycle delay function: prevent the gate from hitting the bicycle;

6.Various control functions: by set the setting, the brake machine can be set at special time to the regular open mode, which satisfies a large number of people.

7.The mode of choice: to meet the different requirements, it can be set up as a two-way credit card or a one-way credit card and free pass.

8.Various control functions: external button, remote control, bar code, IC or ID, etc.

9.Remote control function: the RS485 can be connected to RS485 by computer and the RS485 remote control brake machine.

10.Automatic reset function: after the credit card has not passed in the specified time, the lock will return the lock to cancel the pass, time 1-60 seconds.


1.Power supply:AC220V±10%,50±10Hz
2.working environment:-25℃ to 70℃
3.Relative humidity,≤90% no condensation
4.Input interface:12v level signal or pulse width, > 100ms 12v pulse signal, drive current>10mA
5.communication interface:switching
6.pass direction: one-way or two-way pass time:1-2s
8.Power-on system startup time:3s
9.Number of passers:40 persons/minute
10.lane width:550mm
11.Chassis material: standard 304 stainless steel
12.The shape of the chassis can be customized according to requirements

  • High security for entry control
  • Faster speed and better anti-tailgate performance
  • Connecting rod design result in running smoothly without noise
  • Anti-climbing anti-creeper design can offer strict entry control management
  • Infrared anti-pinch design and mechanical sleeping function(when the barrier is blocked) to ensure the safer passage
  • Sound and light alert for the illegal intrusion, reverse passing, tailgate and overdue passing etc;
  • Gates will auto open when power is off in case of the fire hazard.
  • Application scenarios: Indoor only
  • Anti-tailgate: good
  • Anticollision: good
  • Passing type:pedestrian-only



Test Item Test Environment Quantity Judgment basis(According to customer technical requirements) Test Results Test Conclusion
High temperature test +70℃ 12Hrs 1 PCS The sample can work normally, the appearance, structure and function of the sample are normal After the test, visually check that there is no obvious abnormality in appearance and structure, and it can work normally and function normally Meet the requirements
Low temperature test -30℃ 12Hrs 1PCS The sample can work normally, the appearance, structure and function of the sample are normal Meet the requirements





1.Can you accept OEM or ODM ?
Yes, We provide customized services according to your detailed requirements, also can design unique gate

according to your actual site, and produce different sizes, software and functions.

2. How do you do after-sales service?
We provide life-long technical support online through e-mail, video, telephone, etc., 7*24 hours a day service,

One-year warranty and lifetime technical support.

3. How about the delivery time?
It takes 7-10 working days for regular products. It takes 15-20 working days for customized products.

4.What is your payment method?
T/T 30% as deposit, 70% before delivery. Before you pay the balance, we will show you photos or videos of the

products and packages.
