100W DC Brushless Automatic Lane Barrier Parking Boom Barrier With Straight Pole
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Color | Red/black | Power Supply | 110-240V |
|---|---|---|---|
| Speed | 1.5s | Rated Power | 100W |
| Package | Wood Packing | Boom Length | 1-6 Meters |
| Pole Speed | 2s Movement (1-3s Adjustable) | ||
| High Light | 100W Automatic Lane Barrier,DC Brushless Automatic Lane Barrier,Automatic Parking Boom Barrier |
||
Product Description
DC Brushless Boom car Park rm Barrier Gate
Product characteristics
1.Innovative electronic clutch design: press the electronic clutch switch to unlock when
power off, then the boom can be raised up directly.
2. No limit switch design: the motor can detect the boom position automatically.
3. Bi-direction boom holder design: left-installation and right-installation can be exchanged easily and quickly.
4.Three springs available can extend the spring service life.
5.Auto-detect barrier close after power-on, open/close speed is adjustable.
6. With auto-reversing on obstruction function.
7. Infrared photocell interface is available.(need to install photocell device).
8. Loop detector interface is available, to avoid hitting the vehicle, and control the boom falling down automatically after vehicle passing. (need to install loop detector)
power off, then the boom can be raised up directly.
2. No limit switch design: the motor can detect the boom position automatically.
3. Bi-direction boom holder design: left-installation and right-installation can be exchanged easily and quickly.
4.Three springs available can extend the spring service life.
5.Auto-detect barrier close after power-on, open/close speed is adjustable.
6. With auto-reversing on obstruction function.
7. Infrared photocell interface is available.(need to install photocell device).
8. Loop detector interface is available, to avoid hitting the vehicle, and control the boom falling down automatically after vehicle passing. (need to install loop detector)
9. Built-in counting function, can store the times of opening signal, deduct the times when vehicle passing the loop, boom falling down after vehicle passing through, well improve the traffic efficiency.
10. Built-in delay auto-closing function, coordinated with counting function, if the numbers of vehicle passed less than the stored numbers, the boom will fall down automatically by countdown, but will be new countdown if there is up or loop detector signal.
11. Integrated RS485 communication interface,to realize control of barrier open/close by computer and barrier status query.
12. Integrated RJ45 network interface, to realize control of barrier of barrier open/close by computer network and barrier status query.
13.With auto-aging test function.
14.NO/NC wire control signal input are optional.
10. Built-in delay auto-closing function, coordinated with counting function, if the numbers of vehicle passed less than the stored numbers, the boom will fall down automatically by countdown, but will be new countdown if there is up or loop detector signal.
11. Integrated RS485 communication interface,to realize control of barrier open/close by computer and barrier status query.
12. Integrated RJ45 network interface, to realize control of barrier of barrier open/close by computer network and barrier status query.
13.With auto-aging test function.
14.NO/NC wire control signal input are optional.
| Technical parameter | |
| Model | CW228 |
| Power supply | AC220V±10%,50Hz |
| Working temperature | -25℃~+70℃ |
| Environmental humidity | 5%~95% |
| Direction | left and right direction |
| Length of pole | ≤6m straight pole,≤ 6m curved pole,≤ 5.5m two poles,≤ 4.5m three poles |
| Motor | Capacitor running asynchronous motor |
| Rated capacitance | 8uF/450V |
| Motor rate | 80W,120W |
| Rise and fall time | 1s-3s |
