Servo Motor Barrier Turnstile Gate Pedestrian Security Turnstiles 0.3s High Speed

Place of Origin China
Brand Name Hongchuangwei
Certification CE
Model Number CW427
Minimum Order Quantity 2 piece
Price USD500-900piece
Packaging Details wooden case
Delivery Time 4-9 working days
Payment Terms T/T
Supply Ability 1000 pieces weekly

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Item Name 0.3s Speed Turnstile Gate Motor Servo Motor
Motor Power 40W Open/close Speed 0.3s
Infrared Sensor 8 Pairs Material Stainless Steel
Communication Interface Switch Value, Optional,rs232/485 Number Of Passers 30-50 Persons/minute
High Light

Servo Motor Barrier Turnstile Gate

,

Pedestrian Barrier Turnstile Gate

,

0.3s High Speed Pedestrian Security Turnstiles

Leave a Message
Product Description

0.3s High Speed Security Gate Barrier Turnstile Gate With Servo Motor





Overview:

The turnstile gate Gate opening signal: low level or passive contact signal not less than 100ms , high-end speed pass anti-collision turnstile gate, adopts servo drive + high-speed servo motor, 10 millions working life time,and the door open or close just need 0.3 seconds.with 1.5mm thickness 304 stainless steel case,8 pairs of infrared detection sensors, high stability, high safty and anti-tailing.



Supports various IC/ID card readers, barcode/QR code readers, fingerprint and face recognition devices,easy to hook up with the access control system. It is widely used in the entrance and exit control of tourist attraction,airport,bus or train station,gymnasium, office buildings, high-end residential areas, government, etc.





Technical parameter:
Product model CW427
Input voltage AC220V,110V±10%, 50HZ±10% HZ
Working temperature -40℃-80℃
Relative humidity ≤90% No condensation
Motor servo motor
Rated power 40W
Input control signal Switch value or RS232, 485
Running speed 30~50 people/minute
Infrared beam 8 pairs
Average life span 10 million times
Channel width 600mm~1100mm
Door wing material 10mm acrylic
Product Size L 1600mm x W 120mm x H 980mm
Case material 1.5mm 304 stainless steel
Package weight About 45 KG





Main functions:

1. Pedestrians are authorized to pass through access control methods such as swiping cards or face recognition. Unauthorized entry will be judged as illegal intrusion and alarm
2. It can pass bidirectional or unidirectional, the direction of passage and the speed of opening and closing doors can be adjusted according to needs, and the fastest speed of opening and closing doors can reach 0.3s
3. The turnstile is equipped with a total of 8 pairs of infrared sensors, which can accurately determine whether someone is trailing, and once it is found, it will immediately alarm
4. Infrared and mechanical dual anti-pinch, infrared pre-sensing ensures that someone inside the turnstile will not be forcibly closed, even if the turnstile is closed by mistake and pinches a pedestrian, the door will automatically open to reduce injury
5. Anti-collision function, if someone forcibly enters and impacts the turnstile when the door is closed, the turnstile can withstand a maximum impact of 120Nm
6. With various alarm functions, including automatic detection, automatic diagnosis, illegal intrusion, anti-pinch alarm, anti-tailing alarm, etc.
7. The turnstile can be managed and used remotely through a computer
8. Support online and offline use, users can choose by themselves
9. Equipped with LED traffic indicator, the green light means that it is allowed to pass, and the red light means that it is forbidden to pass.
10. After opening the door for a period of time, if there is no one to pass through for a long time, the machine will automatically close the door, and the length of time for no one to pass can be set by the user.
11. With the power-off turnstile self-opening function, it is convenient for pedestrians to pass safely in fire and other emergency situations





FAQ

1.Can you accept OEM or ODM ?
Yes, We provide customized services according to your detailed requirements, also can design unique gate

according to your actual site, and produce different sizes, software and functions.


2. How do you do after-sales service?
We provide life-long technical support online through e-mail, video, telephone, etc., 7*24 hours a day service,

One-year warranty and lifetime technical support.


3. How about the delivery time?
It takes 7-10 working days for regular products. It takes 15-20 working days for customized products.


4.What is your payment method?
T/T 30% as deposit, 70% before delivery. Before you pay the balance, we will show you photos or videos of the

products and packages.
