Sliding Gate Pedestrian Turnstile Gate 25W Brushless Motor Airport Access Control Systems

Place of Origin Shenzhen,China
Brand Name Hongchuangwei
Certification CE
Model Number CW512
Minimum Order Quantity 2
Price USD 750-800 per piece
Packaging Details wood cases
Delivery Time 5-8 work days
Payment Terms T/T
Supply Ability 100 pieces per day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Model CW512 Power Supply Voltage AC230V
Working Environment Temperature -19℃~75℃ Relative Humidity 96%
IP Protection Level 55 Rated Power 25W
Input Control Signal Switch Quantity Standard Configuration Does Not Include RS232, 485 Running Speed (XX People/minute) 33 People/minute
High Light

Brushless Motor Pedestrian Turnstile Gate

,

25W Pedestrian Turnstile Gate

,

airport access control systems

Leave a Message
Product Description

High and low temperature tested wide passage flap barrier turnstile



A flap barrier turnstile is used when both heightened security and electronic optical turnstile access control are desired. These turnstiles provide a barrier to entry with a very pleasing and inviting appearance. A flap barrier turnstile is often used in office buildings and reception areas, lobbies, modern subway and transit stations, and other high-end building entrances.





Functions & Features
1) Rapid identification technique, available to identify accurately and efficiently the magnetic card, bar code card, ID card and IC card.
2) DC Brushless Motor, Maintenance Free
3) On-line or off –line mode(optional)
4) Real time trouble self-detect and alarm indication, ensuring system safe operation and facilitating maintenance and operation
5) With direction indication, guiding passenger to entry and exit.
6) Self automatic locking to prevent force passing without the card
7) Automatic counting and displaying number of passenger, facilitating observation and with a displaying total amount as high as 90,000
8) Light and sound alarm indication function, preventing illegal entry or irregular passing
9) Powerful on-line intelligent control mode, facilitating you:
A) To adjust the operation speed of the barrier according to the flow of passenger and improve the passing rate.
B) To set up operation mode for passage entry and exit.
C) To read card with multiple times, the special function meeting the application requirements of a particular site.
D) To set up the card reading with or without memory.
E) To select a reasonable normally open or close mode, to divert the flow of passengers effectively.
F) Setting function humanized for reset of over time passing.
10) The infrared sensing technique realizes real time monitor of passage, safe protection and tail-proof.
12) The processing mode in emergency or in special conditions.
13) Having standard input/output port, facilitating the integration of the system and the other equipment, to realize far end control management.
14) Super combination capability, with the combined application of products of different passage types and series, not affecting the system performance.
15) Strong system expending capability, available to add new product at any time
16) Far end control management: function to far end control of barrier mode, meeting the special requirements of the users and the fire protection
17) Resetting automatically. after reading card ,if the passer didn't pass at set time, the system will cancel pass permission automatically, the administrator can set the passing time by himself.
18) Only one person can pass with one card, anti-tag after, anti-hit against
19) Installed in indoor or outdoor
20) Bi-directional passing or single way passing.
21) Ensure rapid,efficient and safe access control
22) No noise,long life





Infrared radio 5 pairs
trouble-free operation 2 million times
average life span 3 million times
Channel width 850mm
Door wing material soft double wings
Product size length 1200mm x width 300mm x height 990 mm
Channel frame 304 stainless steel
Packing weight bout 65 KG (single side lane)
