Flap Barrier Turnstile Retractable Wing Entrance Control Security Automation
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Model | CW503 | Name | Flap Barrier Turnstile |
|---|---|---|---|
| Power Supply | AC220V±10%, 50HZ±10% | Working Temperature | -20℃-60℃ |
| Rated Power | 20W | Chasis Material | Stainless Steel 304 |
| Product Size | 1200*300*990mm | Package Weight | About 55 KG (single Side) |
| High Light | IPX2 Flap Barrier Turnstile,25W Flap Barrier Turnstile,25W wing gate turnstile |
||
Product Description
CW503 Flap Barrier Turnstile Retractable Wing Gate Entrance Control Security Automation
Overview:
CW503 wing gate is a fully automatic intelligent flap barrier turnstile for pedestrian passages. The movement of this turnstile adopts STC CPU chip, DC brushed motor, 6 pairs of infrared detection sensors, with anti-pinch, anti-shock and anti-tailgating functions. The chassis is made of 304 stainless steel, and the door wings are made of plexiglass or soft-wing sponge. The door wing automatically closes after power-on, and when the power is off, the door wing automatically retracts into the chassis to make personnel pass freely, which meets the fire safety requirements. It supports various card readers, barcode readers, ID card readers, QR code recognition, fingerprint recognition, biometric face recognition, etc. It is easy to connect to the access control system. This kind of flap barrier turnstile is widely used in the entrance and exit control of CBD business centers, government and enterprise office buildings, high-end residential areas, kindergartens, etc.
Technical parameter:
| Product number | CW503 |
| Voltage | AC220V±10%, 50HZ±10% HZ |
| Working temperature | -20℃-60℃ |
| Relative humidity | 5%--80% |
| IP protection level | 54 |
| Rated power | 20W |
| Input control signal | RS232, 485 |
| Running speed | 40 people/minute |
| Infrared beam | 6 pairs |
| Average life span | 3 million times |
| Channel width | 550mm |
| Door wing material | 15mm plexiglass, 35mm sponge body with soft wings |
| Product Size | 1200*300*990mm |
| Channel frame | National standard 1.2mm~2.0mm thick + 304 stainless steel |
| Package weight | About 55 KG (single side road) |
Main Functions:
1.Only authorized personnel can pass, and an audible and visual alarm will be issued when unauthorized personnel break in
2.Flexible selection of always open and always closed modes, two-way passing can also be set according to the flow of people, the opening and closing speed of the door wing can be set to improve the efficiency of the equipment
3.Anti-following tracking control technology, strictly preventing unauthorized personnel from passing through
4.Anti-pinch function, when the door wing is blocked during the reset process, it will automatically rebound or the motor will automatically stop working within the specified time, and sound and light alarms will be issued at the same time
5.Anti-shock function, when the door opening signal is not received, the door wing is automatically locked, and the maximum impact force is 120Nm
6.With self-detection, self-diagnosis, and automatic alarm functions; including illegal intrusion alarm, anti-pinch alarm, and anti-tailing alarm
7.Remote control management function
8.It can be run online or offline
9.LED passing direction indication, display passing status
10.When the power is off, the door wings automatically retract into the chassis, the passage is in a clear state, and personnel can pass freely to prevent panic
11.With automatic reset function, after opening the door, the system will automatically cancel the user's permission to pass this time if the user does not pass within the specified time,and you can set the passing time
