Radar Supermarket Entrance Turnstile Automatic Induction Two Way Pedestrian Swing Gate

Place of Origin China
Brand Name Hongchuangwei
Certification CE UL
Model Number CW403
Minimum Order Quantity 2
Price USD380-680 per piece
Packaging Details wood packing
Delivery Time 3-8 days
Payment Terms T/T
Supply Ability 1000 pieces weekly

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Voltage AC220V ,50Hz Working Environment -25℃ To 70℃
Normal Service Life 4 Million Times Number Of Passers 40 Persons/minute
Motor Power 40W IP Protection Level 44
Material Standard 304 Stainless Steel Communication Distance Max 400 Meters
High Light

radar Supermarket Entrance Turnstile


Automatic Induction Supermarket Entrance Turnstile


AC220V pedestrian swing gate

Leave a Message
Product Description

Supermarket entrance radar automatic induction two-way pedestrian swing gate




High-quality stainless steel, infrared induction, power-off opening, reverse prohibition
Automatic reset, smart chip, voice broadcast, stable and durable
Applicable to a variety of places, suitable for all kinds of supermarkets, stores, clothing stores, parks and other places that need to guide import and export, maintain order and standardize access
Selected thickened stainless steel, high strength and high toughness stainless steel, stable and durable, high temperature resistance, corrosion resistance, not easy to oxidize and rust
Power off and open the gate, automatic reset, when encountering a power failure or emergency, the flow of people will be evacuated as soon as possible, safe and reliable

Indicate and control the entry and exit of pedestrians, this model has a small footprint, simple installation, beautiful appearance, and the rebound speed can be adjusted



1.Power supply:AC220V±10%,50±10Hz

2.Input interface: (passive node information number or pulse width)
3.communication interface:switching,RS232 RS485 optional
4.pass direction: one-way or two-way pass
5.working environment:-25℃ to 70℃
6.Relative humidity,≤90% no condensation
7.open/ close time: 1s
8.Power-on system startup time: 3 second
9.Number of passers:40 persons/minute
10.Normal service life: 4 million times
11.Chassis material: standard 304 stainless steel
12.The shape of the chassis can be customized according to requirements


Q1 How fast can I get the quotation?
A We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry as priority.

Q2 Can I get a sample to check the quality of product?

A Yes. We can send you samples to check the quality within 3-5 days.

Q3 How about delivery time?
A Within 1-2 days for standard products in stock. If it is customized order, the delivery time depends on your exact requirements.

Q4 What is the packaging?
A We provide brown carton box, Wooden frame (optional) and wooden box (optional)we also can make your own designed OEM package.

Q5 What is your terms of delivery?

A We accept EXW, FOB, L/C, etc. You can choose the one which is the most convenient or cost effective for you.


Channel width 600mm-1100mm
Swing arm length outside the chassis ≤51cm
Opening speed 0.5 seconds
Number of people passing 40 people/minute
Working environment -40°C~80°C
Relative humidity ≤90%, no condensation
Gate opening signal relay
Cabinet material 304 stainless steel
Box thickness 1.5mm
Drive current >10mA
