0.5s 0.8s High Speed Flap Barrier Turnstile RFID Access Control Pedestrian Swing Gate

Place of Origin China
Brand Name Hongchuangwei
Certification CE UL
Model Number CW408
Minimum Order Quantity 2 piece
Price USD650~880 per piece
Packaging Details wooden case
Delivery Time 6-10 working days
Payment Terms T/T
Supply Ability 1000 pieces weekly

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name High Speed Turnstile Gate Power Supply AC220V±10%,50HZ±10% HZ
Working Environment Temperature -25℃-70℃ Infrared Quantity 7pairs
Relative Humidity ≤90% Number Of Passers 40-60 Persons/min
Face Recognition YES Or No Open Time 0.5s-0.8s
High Light

0.8s Flap Barrier Turnstile

,

High Speed Flap Barrier Turnstile

,

RFID pedestrian swing gate

Leave a Message
Product Description

0.5s 0.8s High Speed Gate Pedestrian Automatic RFID Access Control System Enrance Flap Barrier Swing Turnstile Gate



Product features:



1. Service life: 5 million times

2. Opening speed: 0.3-0.8 seconds

3. Swing arm height:925mm

4. Channel width:550-800mm





Specifications:







Product Model CW408

Machine type



Indoor/Outdoor

Pendulum material

Acrylic/tempered glass

Number of infrared

4 pairs/6 pairs

Equipment size

Length: 1400mm Width: 160mm Height: 1000mm

Box material

SUS304 1.2mm (body) + 1.5mm (upper cover)

Other materials

Side sealing plate 8mm tempered glass

Equipment technology

Wire drawing/grooving

Block collision avoidance

Can be automatically reset by any impact

Run blocked

Automatic return and forced closing can be selected at will

Track detection

Digital technology 360-degree monitoring

Lock brake

Electromagnetic clutch technology

memory function

With multiple people to quickly identify and pass

Power off

Super capacitor (optional)

Channel width

550-800mm

motor

Brushless DC motor

Operating life

3.5-5 million times

Running speed

Customize after 0.8s

Side indicator light

Have

Top light customized



Technical Parameter
Product model CW408
Power supply AC220V±10%,50HZ±10% HZ
Working environment temperature -25℃-70℃
Relative humidity ≤90%
Motor Brushless motor
Rate power 40W
Communication interface Switch value(standard without include RS232,485)
Number of passers 30~40/min
Infrared quantity 7 pairs
Normal service life 5 million times
Channel width size 600mm~1000mm
Swing material 10mm Plexiglass
Product L 1400mm x W 160mm x H 1000 mm
Chassis frame Standard 1.2~1.5mm 304 stainless steel
Packing weight About 80 KG(single channel)









FAQ

1. How strong is your company?

We have more than 200 employees, a 50-person R&D team, 2 factories, more than 60,000 square meters of workshops and office buildings, and 200 product patents.

2. How do you do after-sales service?

We provide life-long technical support online through e-mail, video, telephone, etc., 7*24 hours a day service

3. How about the delivery time?

It takes 7-10 working days for regular products. It takes 15-20 working days for customized products.

4. How long is your warranty period?

One-year warranty and lifetime technical support.

5.What is your payment method?

T/T 30% as deposit, 70% before delivery. Before you pay the balance, we will show you photos or videos of the products and packages.

6.How do we install those revolving doors/barrier doors? Is it easy to do?

Yes, it is really easy to install, and we have done most of the work before sending our product. You only need to fix the gate with screws and connect the power cord and network cable.

7.Can you produce according to our size?

We can provide customized services according to your detailed requirements, and we can also design unique gate products according to your actual site, and produce different sizes, software and functions.

8.What is the warranty of the machine?

Within one year, if there is any problem, we will provide accessories (but you pay the shipping cost)

9.How does your factory control quality?

Quality control in the whole process

10.What is your MOQ?

Any amount is acceptable.
