Low Noise Stainless Steel Turnstiles Swing Gate IP68 With Shock Absorber

Place of Origin Shenzhen,China
Brand Name Hongchuangwei
Certification CE
Model Number CW403
Minimum Order Quantity 10 piece
Price USD300~500 per piece
Packaging Details wooden case
Delivery Time 5-8 working days
Payment Terms T/T
Supply Ability 100 pieces per day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Name Swing Turnstile Material 304 Stainless Steel
Case Thickness 0.985mm Top Cover Thickness 1.115mm
Lane Width 540mm Pass Direction Bidirectional
Waterproof IP68 Outdoor Use Support
High Light

Shock Absorber stainless steel turnstiles


IP68 stainless steel turnstiles


IP68 turnstile swing gate

Leave a Message
Product Description

Low noise face recognition turnstile gate with shock absorber



Product Application

Swing Turnstile ---can be compatible with IC card, ID card, barcode card, fingerprint reading card, face recognition device used for staff, provide civilized, orderly access methods, effectively manage the access of staff. It can be widely used in the station, wharf subway, factories, office buildings, hotels, clubs, intelligent communities, enterprises, and institutions that need intelligent access management.



1. It has a variety of working modes, which can be used for two-way card swiping in and out, and can be swiped on one side, prohibited or free on the other.

2, The fourth generation of automatic anti-collision self-resetting movement, integrated design, stable performance. The unique encoder signal system and precision gear transmission system make the brake lock, unlock and run more accurate and reliable.

3, Anti-collision self-reset design is more advanced. After receiving the opening signal and the rotation signal, the brake lever automatically rotates 120 degrees under the motor drive, one person and one pole. After being hit by an external force, the brake lever is automatically locked and cannot be violently passed; after the external force is released, the brake lever is automatically reset to the middle position.

4. In the case of power failure, the horizontally placed brake lever will automatically drop the lever to ensure that the passage is unobstructed and automatically reset after power-on.

5. Unified and standard external electrical interface, which can be freely docked with various intelligent devices to facilitate system integration and remote control and management through management computer.


Green means passage
Power supply for core
AC100~220V 50/60Hz
Operational voltage
DC 24V ±5%
Voltage of indicator
DC12V ±5%(standard)
Power consumption
Working environment
Indoors or outdoors(outdoor is optional)


Low Noise Stainless Steel Turnstiles Swing Gate IP68 With Shock Absorber 0
