Electronic magnet Control Swing Barrier Turnstile Gate For Access Control
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | 304 Stainless Steel | Case Thickness | 0.983mm |
|---|---|---|---|
| Top Cover Thickness | 1.13mm | Name | Swing Turnstile |
| Card Reading | 5.3cm | Bar Code Scaning | Support |
| QR Code | Support | Fingerprint Identification | 3033 |
| Face Recognition | 20033 | ||
| High Light | AC220V Barrier Turnstile Gate,Electromagnet Control Barrier Turnstile Gate,AC220V swing gate turnstile |
||
Product Description
Electronic magnet Control Swing Barrier Turnstile Gate For Access Control
CW407 high-end swing turnstile gate,using STC CPU chip, DC brushed motor,4 pairs of infrared detection sensors,long life and high stability, efficient anti-tailgating,support various IC/ID card readers,barcode readers,ID card reading,etc.It is easy to connect with the access control system.It is widely used in the entrance and exit control of CBD business centers,government and enterprise office buildings,high-end residential areas,kindergartens, etc.
- Only authorized personnel can pass,and an audible and visual alarm will be issued when unauthorized personnel break in
- Always open and always closed modes can be flexibly selected, and two-way passing can be used.The opening and closing speed of the door wing can also be set according to the flow of people to improve the efficiency of the equipment
- Anti-tailgating tracking control technology to strictly prevent unauthorized personnel from passing through
- Anti-pinch function, when the swing arm is in the process of resetting,it will automatically rebound or the motor will automatically stop working within the specified time, and the sound and light alarm will be issued at the same time
- Anti-shock function,when the door opening signal is not received,swing arm is automatically locked,maximum impact force is 120Nm
- With self-detection,self-diagnosis,automatic alarm functions; including illegal intrusion alarm, anti-pinch alarm, and anti-tailing alarm
- Remote control management function
- Can be run online or offline
- LED passing direction indication, display passing status
- When the power is cut off, he swing arm is automatically opened,the passage is in an unobstructed state,and personnel can pass freely to prevent panic
- With automatic reset function,after opening the door, the system will automatically cancel the user's permission for this passing if the user does not pass within the specified time,and you can set the passing time
| Technical parameter | |
| Product number | CW407 |
| Voltage | AC220V±10%, 50HZ±10% HZ |
| Working temperature | -25℃-70℃ |
| Relative humidity | 5%--80% |
| Rated power | 20W |
| Input control signal | Switch quantity (standard configuration does not include RS232, 485) |
| Running speed | 30~40 people/minute |
| Infrared beam | 4 pairs |
| Number of trouble-free runs | 2 million times |
| Average life span | 3 million times |
| Channel width | 500~910mm |
| Swing arm material | 10*560*497.5 Acrylic |
| Product Size |
1400*180*990mm(single movement) 1400*286*990mm(dual movement) |
| Channel frame | 1.0~1.3 thick 304 stainless steel |
| Package weight | About 55 KG (single side road) |
