LED Indicator 50Hz Automatic Pole Barrier Gate For Driveway

Place of Origin Shenzhen,China
Brand Name Hongchuangwei
Certification CE
Model Number CW238
Minimum Order Quantity 10 piece
Price USD 180-230 per piece
Packaging Details wood cases
Delivery Time 5-8 working days
Payment Terms T/T
Supply Ability 100 pieces per day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Power Supply AC220V±10%, 50Hz Working Temperature -40℃ To +80℃
Ambient Humidity 5% To 95% Fixed Direction Can Be Interchanged Left And Right
Pole Length ≤ 6 Meters Straight Rod Motor Capacitor Running Asynchronous Motor Or DC Brushless Motor
Rated Capacitance 6uF/450V Motor Power 80W, 120W
High Light

50Hz Pole Barrier Gate

,

LED Indicator Pole Barrier Gate

,

50Hz automatic barrier gate

Leave a Message
Product Description

AC alternating current straight pole barrier gate with LED indicator





Product Overview

Our company specializes in the production of integrated intelligent barrier gates,which are designed and manufactured with international

leading technology,and realize the operation of the gate is automated,intelligent,safe,convenient and fast to use.



Product performance
1. Special rotating structure,no gear,no belt rotation,no maintenance,stable use,long life
2. The specially designed balance structure enables the brake lever to start slowly,run quickly,and stop slowly.
3. The jitter caused by the operation of the brake lever is eliminated.
4. The brake lever runs permanently at 90 degrees,and the 360-degree operation accident occurs after troubleshooting.
5. Specially designed low-speed aluminum housing motor,gearbox one-piece design,low noise,fast heat dissipation.
6. The drive mechanism is designed with an intelligent overheating protection system to control the temperature rise of

    the motor under frequent use.Make the motor not easy to burn out.



Take-off and landing time 1.5S 3S 6S
Working temperature -25℃~+75℃
Working humidity ≤90%, no condensation
Power supply AC 220V/50HZ
Fuse specification φ5×20 5A
Power output DC 12V ≤0.2A
Fall limit output dry contact signal, normally open
Ceiling output dry contact signal, normally open
Receiver working voltage DC 5V
Encoder working voltage DC 5V
Operating voltage of limit switch DC 5V



LED Indicator 50Hz Automatic Pole Barrier Gate For Driveway 0LED Indicator 50Hz Automatic Pole Barrier Gate For Driveway 1
